SIZE :6.5"INCH MIDRANGE SPEAKER
POWER: 100W RMS / 200W MAX
VOICE COIL: 1.5" KSVCCAW
MAGNET: 115*60*15 20.5 OZ,Y35
WIDTH OF COPPERWIRE: 8MM
IMPEDANCE: 4 OHMS
FREQ.RESP.: 100HZ-11KHZ
SENSITIVITY: 96 DB //M.
8 INCH MIDRANGE SPEAKER
SIZE: 8”INCH MIDRANGE SPEAKER
POWER: 150W RMS /300W MAX.
VOICE COIL: 2” KSV CCAW
MAGNET:134*60*15, 30.5OZ,Y35
WIDTH OF COPPERWIRE: 11MM
T-YOKE THICKNESS: 6MM
IMPEDANCE: 4OHMS
FREQ.RESP.: 93HZ-10KHZ
SENSITIVITY: 94 DB /W/M.
10 INCH MIDRANGE SPEAKER
SIZE: 10 " INCH MIDRANGE SPEAKER
POWER: 200W RMS /400W MAX.
VOICE COIL: 2.4” KVC CCAW
MAGNET: 156*70*15, 38 OZ, Y35
T-YOKE THICKNESS: 14MM
IMPEDANCE: 4 OHMS
FREQ.RESP.: 85HZ-9KHZ
SENSITIVITY: 92 DB /W/M.
