Products

FQB

Details:

DESCRIPTION

ModelFQB1500DFQB250FQB450FQB4.1FQB5.1
Channels:1 CH Digital2 CH Mosfet4 CH Mosfet5 CH Mosfet6 CH Mosfet
RMS Power:500WX1 @ 4Ohm50WX2 @ 4Ohm50WX4 @ 4Ohm50WX4 @ 4Ohm+180WX150WX5 @ 4Ohm+150WX1
Low Pass   Frequency:30Hz - 300Hz40Hz - 240Hz40Hz - 240Hz/180Hz
High Pass   Frequency:/40Hz - 240Hz40Hz - 240Hz/180Hz
THD:≤0.5%≤0.5%≤0.5%≤0.5%≤0.5%
S/N Ratio:≥90dB≥90dB≥90dB≥90dB≥90dB
Bass Boost Center Frequency:50Hz50Hz50Hz30Hz - 300Hz30Hz - 300Hz
Bass Boost :0 - 18dB0 - 6dB0 - 6dB0 - 18dB0 - 18dB
St   Separation(+A):/≥50dB≥50dB≥50dB≥50dB
Frequency   Response:10Hz - 20KHz10Hz - 20KHz10Hz - 20KHz10Hz - 20KHz10Hz - 20KHz
Auto   Protection;Thermal(75 ℃ ), Overload, Short, Reverse Polarity, Speaker Shortcut   Protection
Dimensions180X245X55mm180X245X55mm290X245X55mm400X245X55mm450X245X55mm
